SRS Black Active Infrared Exit Sensor with IP45 Weather Resistance
£106.43
£88.69
SKU
CM-RQE70-B
- This product is available to order. The lead time is normally 2 – 4 working days.
- An accurate despatch date will be confirmed with you once order is received by our sales team (during office hours).
Free Delivery on this product
SRS CM-RQE70-B Black active infrared exit sensor with 12-24Vdc/Vac operating voltage. With an installation height of 3000mm and IP45 weather resistance
SRS CM-RQE70-B Black Active Infrared Exit Sensor with IP45 Weather Resistance
Black active infrared exit sensor with 12-24Vdc/Vac operating voltage. With an installation height of 3000mm and IP45 weather resistance.
Features:
- Colour: Black
- Active infrared
- Installation height 3000mm (9.8ft max)
- IP45 Weather resistance
- Response speed 0.1~0.2s
Technical Specifications:
- Operating voltage: 12~24Vdc/Vac
- Voltage tolerance: ±10%
- Current draw: AC12V-1.7[VA] (Max), DC12V-110[mA] AC24V-2.1[VA] (Max), DC24V-60 [mA]
- Operating temperature (C): -20 to +60
- Humidity: 0~95% non-condensing
- Test input 6[mA] (Max)@24[VDC]
- Relay hold time 0.5 sec
Dimensions:
- 45 x 360 x 45 (hwd mm)
| Brand | SRS |
|---|---|
| Operation | Hands Free (PIR) |
| Finish | Plastic |
| Accessories - Entry Exit - Mounting | Surface mount |
