Fermax Radio Frequency 868MHz System Kit for Shops

Fermax F-5249 RF 868MHz Radio Frequency System Kit for Shops

The Fermax F-5249 is a complete radio frequency door opening kit operating at 868.35MHz with rolling-code encryption. Designed for shops, garages and single-family homes, it enables remote door activation from up to 100 metres using handheld RF transmitters.

The kit includes a dual-relay receiver capable of managing up to 500 codes and three Keysingle Mini transmitters. Each transmitter features the exclusive APS (Approaching System) which continuously transmits the signal after button press, allowing the user to activate the remote while still out of range and have the door open as they approach. The receiver supports both manual and radio-based programming, with Relay 1 configured as monostable and Relay 2 switchable between monostable and bistable modes via an internal jumper.

Key Features

• 868.35MHz rolling-code encryption for secure access
• APS Approaching System for extended activation range
• Receiver manages up to 500 unique codes
• 2 relay outputs: Relay 1 monostable, Relay 2 monostable or bistable (jumper selectable)
• Manual or radio-based receiver programming
• Each transmitter has 2 pushbuttons for dual device activation
• Suitable for shops, garages, single-family homes and communal areas

Kit Contents

• 1 x RF Basic-2B receiver (ref. 5250) - up to 500 codes
• 1 x 12Vac 1A power supply (ref. 4802)
• 3 x Keysingle Mini transmitters (ref. 5259)

Technical Specifications

• Frequency: 868.35MHz
• Codification: Rolling code with changing security code
• Receiver memory: 500 codes
• Relay outputs: 2 relays, 1A contacts
• Power supply: 12/24Vac/dc +/-10%
• Standby consumption: 60mA
• Active consumption: 90mA
• Operating temperature: -20 to +85 degrees C
• Protection class: IP54 (IP65 with cable gland)
• Transmission range: up to 100 metres
