Comelit Repeater Module for ViP System
£119.98
£99.98
SKU
1447
- This product is available to order. The lead time is normally 2 – 4 working days.
- An accurate despatch date will be confirmed with you once order is received by our sales team (during office hours).
Free Delivery on this product
Comelit 1447 ViP System Active Repeater Module. 10/100 Mbit/s signal repeater with two RJ45 ports, up to 8 units in cascade.
Comelit 1447 Active Repeater Module for ViP Door Entry Systems
The Comelit 1447 is a 10/100 Mbit/s active signal repeater module for the Comelit ViP (Video over IP) door entry system. It extends network distances beyond the standard cable run limits by regenerating the signal between ViP devices. The module features two RJ45 connectors (PSE input and PD output) and does not require a local power supply as it draws power from the input port and passes it through to the connected device. Up to 8 repeater modules can be connected in cascade for maximum distance extension.
Key Features
- Extends ViP system network distances beyond standard limits
- Two RJ45 ports (PSE input and PD output)
- No local power supply required - powered via input port
- Up to 8 units can be connected in cascade
- 10/100 Mbit/s active signal repeater
- DIN rail mounting - 4 DIN modules
- Compatible with all ViP system devices
Technical Specifications
- Power supply: 36/57 VDC, 3A max (via PoE input)
- Absorption: min 0.7 W, max 2.6 W
- Connectors: 2x RJ45 (PSE/PD)
- Maximum cascade: 8 devices
- Connection distance at 10 Mbit/s: up to 250 m per segment
- Connection distance at 100 Mbit/s: up to 120 m per segment
- Operating temperature: -30 to +55 degrees C
- Mounting: DIN rail, 4 DIN modules
Dimensions
- 36 x 65 x 83 mm (H x W x D)
Attachments
| Brand | Comelit |
|---|---|
| Product Type | System Expander |
